SMSL DO200 MQA FULL DECODING

USB /OPT/Coaxial/AES inputs support MQA decoding function, and support MQA-CD. All input ports support DSD ( Except BT ) , coaxial , opt and AES support Dop64.

HIGH QUALITY CHIPSET

2 x advanced ES9068AS D/A chips, THD + N as low as122dB. 5 x High-end dual op amp OPA1612A and a large number of audio gradecomponents. XMOS XU-216, a true 32bit USB solution, supporting Dop256 and native DSD512, PCM supports up to 768KHZ.

BLUTOOTH5.0 DAC

Qualcomm's latest Bluetooth chip supports LDAC 24bit/96khz, APTX/HD, SBC, AAC. Wireless Bluetooth connection is more convenient. SMSL DO200 can turn a CD player that does not support MQA into an MQA-CD player, not only MQA rendering, but SPDIF supports MQA full expansion.

LOW NOISE POWER SUPPLY

Discrete component linear power supplies and multiple low-noise power supplies specially designed for analog circuits, while improving power efficiency and lower power consumption.

FULL-FUNCTION REMOTE CONTROL

Full-view color IPS display with dimmer function. Equipped with full-function remote control. High-quality gold-plated input and output connection terminals. With HI-RES certification.

Technical Details

Product mode
SMSL DO200
THD+N
0.00008%(-122d8)
Dynamic range
XLR 129dB; RCA 125dB
SNR
128dB
Output impedance
100Ω
Input
USB / Optical / Coaxial /Bluetooth / 12S / AES / EBU
Output
RCA / XLR
USB transmission
Asynchronization
USB
1bit, 16-32bit
Optical / Coaxial / AES / EBU
1bit, 16-24bit
USB/ I2S
PCM 44.1-768kHz; DSD 2.8224~22.5792MHz
Optical / Coaxial / AES / EBU
PCM 44.1-768kHz; DSD64(DoP)
Bluetooth specification
BT 5.0 ( support SBC / AAC / APTX / APTX HD / LDAC )
Power Consumption
5W
Standby power
<0.5W
Size
210 X 40 X 170mm ( WxHxD )
Machine weight ( including remote control )
1.2KG
Packing weight
1.9KG
Package list
1* SMSL DO200
1* Remote control
1* Bluetooth antenna
1* USB cable
1* AC power cable
1* User manual
1* Warranty card
Inside the Box
  • 1 x SMSL DO200
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The SMSL DO200 Comes with a 1 year warranty on the DAC only. Warranty doesn't apply to the included accessories.
