SMSL VMV D3

Advanced R-2R Desktop Digital to Analog Convertor

    High-End XMOS Second-generation 16-core Processor
    Excellent All-Aluminum Alloy Shell
    Professional and Precise Circuit Design
    Leading Noise Reduction Technology
    High-Grade All-Aluminum Remote Control
Regular price $3,499.99 USD
Sale price $3,499.99 USD Regular price

High-End Chipset

The SMSL VMV D3 features a marvelous XMOS second-generation 16-core processor XU216 paired with the clock system featuring two American ACCUSILICON ultra-low phase noise crystal oscillators and ALTERA’s high-speed CPTD. This chipset provides jitter-free and high-quality sound rich with details. The D3 also features built-in low clock jitter VCXO and PLL which can support access to external clock.

Excellent All-Aluminum Alloy Shell

The VMV D3 comes with an excellent visual appearance with an integrally formed aluminum alloy shell, which effectively prevents oxidation. The use of non-magnetic raw materials can not only shield the interference of external magnetic fields but also have no magnetic fields. The D3 can reduce the noise and further improve the quality of music. It is worth mentioning that the power supply and the motherboard are designed separately to effectively isolate the power supply interference.

Professional and Precise Circuit Design

The SMSL VMV D3 characterizes four pieces of American legendary R-2R chip PCM1704U-J from BB with two chips per channel. These are fully balanced designs to maximize chip performance. Besides, the VMV D3 features top digital filter chip SM5847, the world recognized technical indicators of the most advanced latest boutique currently to improve our audio experience.

Leading Noise Reduction Technology

The VMV D3 follows with a kind of power supply voltage regulator circuit with specially developed low-noise discrete component and custom low-noise pooted toroidal transformer manufactured by UK Noratel. It also features seven OPA1612 top op amps from US TI, a low noise and high precision operational amplifier specially designed for audio circuits.

High-Grade All-Aluminum Remote Control

SMSL VMV D3 characterizes a color LCD display on the front with newly developed user interface that shows basic information like active input type, and more information. This remote controller is fully operational using the remote control with ease.

Inside the Box

  • 1 x SMSL VMV D3
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

Technical Details

Specifications
Input:USB / Optical / Coaxial/AESIEBU)
Output :RCA/XLR
THD+N :0.001%
Dynamic range :112dB
SNR: 112dB
USB transmission :Asynchronization
USB compatibility: Windows 7/8/8.1/10, Mac OSX、Linux
Bit depth: USB/ IPS 1bit,16- 32bit
Optical / Coaxial/AES(EBU):1bit,16- 24bit
Sampling rate :USB/ PS PCM 44.1 ~768kHz
DSD :2.8224-22.5792MHz
Optical / Coaxial/AES(EBU) PCM: 44.1 ~192kHz
Power Consumption: 10w
Standby power:<0.8w
Size :28OX240X51mm (WxHxD)
Weight :3.96kg

Processing Time

This product is in Pre-order period. Pre-orders are provided for items that have not reached us and will take some time to be shipped out.

Pre-order Period: Expected to be available in early December
