TOPPING PA5 II / PA5 II Plus

High-Performance Decktop Power Amplifier

    Fully Balanced Structure
    Immersive Sound Experience with Minimal Distortion
    High Output Power
    Comprehensive Circuit Protection
    Perfect Matching and Expandability
    Special partner-D10 Balanced
Black
Silver
Regular price $249.00 USD
Sale price $249.00 USD Regular price

Fully Balanced Structure

The PA5 II and PA5 II Plus amplifiers offer a fully balanced structure and innovative Class D amplifier circuitry, ensuring high power and low distortion sound output. The engineers' exceptional tuning technology guarantees a clear, clean, and deep sound with no audible noise floor. With the fully balanced structure, the PA5 II/PA5 II Plus eliminates hum, noise, and ground loop issues.

Immersive Sound Experience with Minimal Distortion

These amplifiers achieve distortion levels as low as an excellent digital-to-analog converter (DAC). When delivering 5W into a 4 Ω load, the THD+N is below 0.0004%, and when outputting 5W into an 8 Ω load, the THD+N is below 0.0003%. Such remarkably low distortion levels enhance your music experience significantly.

High Output Power

With high output power, the PA5 II Plus can deliver up to 140W x 2 for 4-ohm loads at 10% distortion, and even at 1% distortion, it can still provide 125W x 2 for 4-ohm loads. Similarly, the PA5 II can output 100W x 2 for a 4-ohm load at 1% distortion. These amplifiers possess both high output power and low distortion characteristics, making them suitable for most speakers and usage scenarios.

High Output Power

With high output power, the PA5 II Plus can deliver up to 140W x 2 for 4-ohm loads at 10% distortion, and even at 1% distortion, it can still provide 125W x 2 for 4-ohm loads. Similarly, the PA5 II can output 100W x 2 for a 4-ohm load at 1% distortion. These amplifiers possess both high output power and low distortion characteristics, making them suitable for most speakers and usage scenarios.

Perfect Matching and Expandability

For an excellent match, the E50 DAC with pre-amplifier functionality shares the same design language as the PA5 II series amplifiers. The TRS balanced transmission between the DAC and amplifier ensures high-fidelity signal transfer without the risk of ground loop interference or environmental disturbances, fully unleashing the potential of the PA5 II amplifiers and your speakers. When a more comprehensive system is desired, combining the PA5 II series power amplifiers, E50 DAC, and L50 Headphone amplifier is recommended. This setup ensures corresponding devices from the digital audio source to the speakers and headphones, meeting all your audio needs.

Special partner-D10 Balanced

As a special partner, the D10 Balanced offers high-fidelity USB decoding and TRS balanced output. When used in conjunction with the PA5 II series amplifiers, it adds a high-performance USB input to the amplifiers. This combination provides a concise and efficient solution when USB input and amplifier output are the primary requirements.

Inside the Box

  • 1 x TOPPING PA5 II / PA5 II Plus
  • User Manual

1 Year Warranty

The TOPPING PA5 II / PA5 II Plus Comes with a 1 year warranty on the AMP & DAC only. Warranty doesn't apply to the included accessories.

Technical Details

Product Dimensions
16.6*12.9*4.1cm
Weight
680g
Power input
PA5 II: DC38V/3.0A | PA5 II Plus: DC38V/4.0A
Inputs
RCA, TRS
Outputs
Speaker terminal
Power on/off
Switch/trigger signal
Volume control
Analog potentiometer
Display
White LED
Standby power consumption
<0.5W
