ALL TO DSD512 Output

Introducing ACMEE Magic Sound V, a revolutionary USB and Bluetooth HiFi decoder amplifier. Combining USB decoding with Bluetooth LDAC, it delivers an extraordinary audio experience with ALL TO DSD512 output and advanced SRC upscaling technology. Crafted with precision and innovation, it boasts the unique Jidian Clean Land 2.5 technology and an independent audio board design, ensuring pure, high-quality sound.

Exceptional Craftsmanship

Marvel at the vibrant play of colors and shadows on the glass surface of Magic Sound V. The exquisite craftsmanship and intricate texture create an overall slim and lightweight design. Complemented by an aluminum alloy frame with a refined sandblasted deep gray anodized finish, the delicate engraved font adds a touch of sophistication, providing a tactile and elegant feel.

Bluetooth Excellence & USB Superiority

Equipped with the QCC5125 module, Magic Sound V supports LDAC, APTX, and other encoding formats for exceptional Bluetooth performance. On the USB front, it offers practical 384K/32BIT bitrate support, ensuring a versatile and high-quality audio experience.

Powerful Internal Configuration

Magic Sound V's power configuration is built on a foundation of PE materials. With a stack of KDS low-phase noise crystals, 47uF large-capacity capacitors, MUSES8920 op-amp, and the mature ES9038Q2M symmetric circuit design, it achieves a remarkable balance of power, clarity, and efficiency.

Dual-Device Connectivity

Magic Sound V supports simultaneous connections to both a computer and a smartphone, automatically switching to the device with an active audio signal. This feature is a game-changer for gamers, offering wireless, almost zero-latency, high-fidelity sound transmission for an immersive gaming experience.Addressing the needs of Android enthusiasts, Magic Sound V serves as a boon for those who desire a seamless audio experience. It eliminates the dilemma of choosing between a smartphone and a dedicated player, providing a solution that enhances both audio quality and convenience.

Heat Management & Versatile Connectivity

Designed with efficient heat dissipation, Magic Sound V remains cool even under full power operation. It supports 4.4mm and 3.5mm dual interfaces, with the 3.5mm port featuring optical fiber output, supporting 192K/24BIT or 96K/24BIT. The device is also equipped with SRC audio upscaling and A2D (ALL-TO-DSD) functionality for an advanced audio experience.

Lightweight & Long-Lasting

With a total weight of approximately 112 grams and dimensions of 112MM63MM11MM, Magic Sound V is lightweight and portable. It ensures a battery life of over 10 hours in light usage (normal Bluetooth connection), alleviating concerns about battery anxiety during home or travel use.

Fast Charging & Future Upgradability

Magic Sound V supports fast charging protocols, delivering a charging power of up to 18W for a complete charge in around 40 minutes. Additionally, it allows for firmware upgrades, ensuring that your audio experience remains cutting-edge with evolving technologies.

Technical Details

Bluetooth parameters
LDAC/APTX/ SBC.....
USB Sampling
PCM:384K/32Bit | DSD: Native 256/Dop 128
Output Power
Single: 245mW(32Ω) | Balance: 980mW(32Ω)
Dimensions
13(L) x 10(W) x 4.5(H) cm
Signal to Noise Ratio
Single: 115dB | Balance:118dB
Total Harmonic Distortion
0.000015
Frequency Response
20Hz-45kHz
Chip configuration
DAC: ES9038Q2M | Operational Amplifier: MUSES8920*2 | Headphone Amplifier: RT6863*2
Audio Power Supply
士5.5V*2
DAC Power Supply
LDO*7 | DCDC-5V*2
Input
TYPEC DAC/TYPEC CHARGE
Output
3.5 PO/44balance/SPDIF-3.5MM
Material
6060 aluminium
Size
112mm*63.5mm*11mm
Weight
112.8g
Inside the Box
  • 1 x ACMEE Magic Sound V
  • User Manual
