ALTERA High Efficiency Chip

The heart of the Taurus R2R DAC is powered by an advanced ALTERA chip, ensuring distortion-free audio signal transmission that meets the HIFI standard. Experience unparalleled clarity and precision in your audio playback.

Self-Developed Digital Filters

Our self-developed digital filter, featuring a 16 X Over Sampling mode, enhances dynamic contrast, analytical power, and achieves a natural and delicate tone. With 32bit input resolution at each filtering level, your audio experience reaches new heights of fidelity.

R2R Arrays

Each channel is equipped with an independent high-speed FPGA controlling decoding through 4 sets of R-2R networks. This design minimizes linear error, ensures high decoding speed, and reduces digital noise, guaranteeing low distortion and minimal background music noise. The Panasonic R2R resistor with a remarkable accuracy of +0.005% adds to the exceptional quality.

Thermostatic Dual Crystal Oscillator

The Taurus R2R DAC incorporates an AT-cut thermostatic crystal oscillator, known for its superior frequency stability and accuracy. The internal temperature control circuit ensures a constant temperature, allowing the Crystal Oscillator to achieve the highest level of frequency stability.

USB Solutions

Featuring the STM32F446 chip driving a proprietary USB audio solution, the Taurus R2R DAC supports 24bit/1536KHz PCM data stream and DSD up to DSD1024. Enjoy a seamless audio processing experience with uncompromised quality.

Clock Outputs for Synchronization

With two clock outputs (49.152MHz, 45.1584MHz), the Taurus offers synchronization for multiple audio devices. Achieve synchronized audio output across multiple channels, ensuring a cohesive and immersive listening experience.

Technical Details

Sample Rate(OPT input)
4.3Vrms/2.58Vrms
Distortion
<0.0015%
Frequency response
20HZ-80KHz
SNR
≥127dB
Separation(0dB)
≥132
Phase(0dB)
0.001 deg
DC Output Voltage
≤2uv
Inside the Box
  • 1 x MUSICIAN Taurus
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

Most products within our store come with a 1 year warranty. Please check our terms of service to see more.

Processing Time

This product is in Pre-order period. Pre-orders are provided for items that have not reached us and will take some time to be shipped out.

Pre-order Period: 1 week.

Note:

  • No cancellation of orders once ordered.
  • All orders to be shipped out sequentially.
