Outstanding THX-888 Module

S.M.S.L SH9 utilizes the certified THX-888 module with outstanding audio performance and power to let you enjoy high-fidelity sound anytime. Patented feed-forward error correction topology provides lower coloration and distortion and natural sound.

Precise Bipolar Linear Circuit

The SH-9 features a THX AAA-888 circuit, a Bipolar linear amplifier circuit with patented feed-forward error correction topology, nulling conventional distortion mechanisms and reducing harmonic, intermodulation, and crossover distortion. Besides, it adopts a high-quality 256-bit volume control relay with a clicking-free design.

Efficient Power Supply

The SMSL SH-9 characterizes a high-efficiency ultra-low-noise power supply, which is S.M.S.L Patented 24W low noise high efficiency power back up for superb audio performance and output efficiency.

Gorgeous CNC Milled Aluminum Alloy Shell

The SH-9 features an excellent visual appearance with a whole piece of tempered glass on the top and an integrally formed aluminum alloy shell, which effectively prevents oxidation. The use of non-magnetic raw materials can not only shield the interference of external magnetic fields but also have no magnetic fields. It is worth mentioning that the SH-9 can bring a delicate, smooth finish and reliable durability.

Unique Thermal Protection

The SMSL SH-9 follows with high precision resistors for temperature stability that can be used to protect electronic systems. High temperatures can destroy electronic components. That's why many electronic systems use temperature sensor ICs to monitor system heat levels and avoid thermal problems.

Technical Details

Audio Part
Input: Balanced*1 Single end*1
Output: Balanced*1 Single end*1
Output Power:
6W*2@16Ω
3w*2@32Ω
440mW*2@300Ω
220mW*2@600Ω
SNR: 137dB, A-Weighted
Remaining Noise: 1.9uV, A-Weighted
THD+N: -123dB,0.00006% (A-Weighted)
THD+N: -117dB 0.00013 (20-20kHz, 320, -3dB)
THD: THD: -125dB,0.00006% (1kHz, 160, -3dB)
Input Impedance: 47kΩ
Output Impedance: Near 0Ω
Frequency Response: 0.1Hz-500kHz(-3dB)
Gain: Low(+0dB), High(+10dB)
Other Parts
Voltage & Frequency: AC100-240V,50-60Hz
Energy Consumption: 24W
Standby Power: <0.1W
Dimensions: 187.5*154*40(mm)
Packaging Dimensions: 282*232*79(mm)
Weight: 790g
Inside the Box
  • 1 x SMSL SH-9
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The SMSL SH-9 Comes with a 1 year warranty on the DAC & Amplifier only. Warranty doesn't apply to the included accessories.

Processing Time

This product is in Pre-order period. Pre-orders are provided for items that have not reached us and will take some time to be shipped out.

Pre-order Period: Expected to be available in early December
