Flagship achievement flagship

D90LE uses ESS SABRE ES9038PRO, with 32bit Hyperstream architecture, achieves ultra-high performance in the audio field. Each channel of the D90LE will be arranged in parallel by 4 conventional balanced channels. This makes the performance of D90LE even better.

Bluetooth 5.0 LDAC transmission

D90LE has the certification of Hi-Res Audio Wireless and LDAC. It uses CSR8675 chipset to support LDACIAAC/SBC/APTX/APTX LL/APTX HD protocol.To get even better sound quality from Bluetooth, we abandon the built-in DAC of CSR8675 and connect it'sdigital signal to ES9038PRO to decode. We use CPLD to process the clock and greatly optimize the digital signal, so that regardless of USB, optical, coaxial, AES input, Jitter is lower than -160dB .

Preamplifier function

In addition to the DAC mode with a fixed output level, theD90LE also has a DAC+ preamplifier mode.In this mode, you can control the output volume on the front panel or at the remote control. This will provide great convenience when connected to a power amplifier or monitor speakers.And also help you leave the budget of a preamplifier. Turn your PC into a HIFI source: D90LE uses 2nd generation XMOS, USB supports up to PCM32bit768kHz and DSD512 native.

Selectable output

D90LE has balanced XLR output and single ended RCA output. You can choose "XLR only", ¡°RCA only" or "XLR+ RCA" output to for different applications.

Sound simulation

According to the unique harmonic performance of tubes and transistors, we added the sound simulation function of tubes and transistors to the D90LE£¬so that you can hear 3 different performance.

Technical Details

PCM
USB IN: 44.1kHz-768kHz/16bit-32bit
IIS IN: 44.1kHz-768kHz/16bit-32bit
COAX/OPT/AES IN: 44.1kHz-192kHz/16bit-24bit
BT IN: AAC/SBC/APTX/APTX LL/APTX HD/LDAC
DSD( Native )
USB IN: DSD64-DSD512
IIS IN: DSD64-DSD512
COAX/OPT/AES IN: Not supported
BT IN: Not supported
DSD(DoP)
USB IN: DSD64-DSD256
IIS IN: DSD64-DSD256
COAX/OPT/AES IN: DSD64
BT IN: Not supported
MQA
USB IN: Not supported
IIS IN: Not supported
COAX/OPT/AES IN: Not supported
BT IN: Not supported
D90LE Decoding parameters (USB In@96kHz)
THD+ N@A-wt: <0.00007% @1kHz
THD @No-wt 90kBw: <0.0008% @20-20kHz
SNR@A-wt: 127dB @1kHz
Dynamic range@A-wt: 127dB @1kHz
Frequency Response: 20Hz- 20kHz(±0.1dB); 20Hz-40kHz(±0.3dB)
Output Level: 2.1Vrms @0dBFS (4V Mode); 2.6Vrms @0dBFS (5V Mode)
Noise @A-wt: <1.3uVrms
Crosstalk: -124dB @1kHz
Channel Balance: 0.3 dB
Output Impedance: 100Ω
LINE OUT XLR
THD+ N@A-wt: <0.00005% @1kHz
THD @No-wt 90kBw: <0.0003% @20-20kHz
SNR@A-wt: 134dB @1kHz
Dynamic range@A-wt: 134dB @1kHz
Frequency Response: 20Hz-20kHz(±0.1dB); 20Hz-40kHz(±0.3dB)
Output Level: 4.2Vrms @0dBFS (4V Mode); 5.2Vrms @0dBFS (5V Mode)
Noise @A-wt: <1.1uVrms
Crosstalk: -139dB @1kHz
Channel Balance: 0.3 dB
Output Impedance: 100Ω
Inside the Box
  • 1 x TOPPING D90LE + TOPPING A90
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The TOPPING D90LE + TOPPING A90 Comes with a 1 year warranty on the AMP & DAC only. Warranty doesn't apply to the included accessories.
