Flagship DAC ES9028PRO Chip

Equipped with ESS SABRE flagship DAC ES9028PRO chip with a 32-bit 8-channel Hyper Stream¢òarchitecture, the TOPPING E70 features every 4 channels connected in parallel as one channel to achieve excellent audio performance and sound quality at the same time. Besides, the E70 characterizes super audio reproduction ability.

Brand-New I/V Conversion Circuit

The TOPPING E70 adopts a brand-new l/V conversion circuit for better quality audio reproduction. This unique circuit design provided lower distortion, lower noise while occupying less space. It is also pushed close to the limit of physics so that we can squeeze out the last bit of performance of the DAC chip.

Bluetooth 5.1 LDAC Transmission

Featuring the certification of Hi-Res Audio Wireless and LDAC, the TOPPING E70 utilizes the latest QCC5125 chipset to support LDAC/ AAC/ SBC/aptX/ aptX LL/ aptX HD/ aptX-Adaptive protocol by Bluetooth 5.1. To get even better sound quality from Bluetooth, the E70 abandons the built-in DAC of QCC5125 and connect its digital signal to ES9028PRO to decode.

Latest XMOS XU316 & Thesycon Custom Driver

The USB input of E70 characterizes a wide range of compatibility: Windows 10, Windows11£¬MAC£¬Linux£¬IOS£¬and Android. Only for Windows ASIO applications, you need to install the driver and set it up. The USB hardware is based on the newest XMOS XU316 and Thesycon custom driver (applicable to Windows, other systems are free of driver), which is stable and reliable.

Designed For Matching with L70

L70 and E70 have fully matched design languages and styles. L70 is suitable for almost all kinds of headphones. The E70 and L70 can be switched on and off through the 12V Trigger interface, so that the L70 can be synchronized with the automatic or manual on/off the E70.

Technical Details

PCM
USB IN:
44.1kHz-768kHz/
16bit-32bit
COAX/OPT IN:
44.1kHz-192kHz/
16bit-24bit
BT IN:
AAC/SBC/APTX/
APTX LL/ APTX HD/
APTX-Adaptive/LDAC
DSD(Native)
USB IN: DSD64-DSD512
COAX/OPT IN: X
BT IN: X
DSD(DoP)
USB IN: DSD64-DSD256
COAX/OPT IN:
DSD64
AACISBC/APTX/
BT IN: X
E70 DAC parameters:(Line Out/USB In@96kHz)
RCA
THD+N @1kHz (A-wt): <0.00008%
THD+N @20-20kHz 90kBw (No-wt): <0.00007%
SNR@1kHz(A-wt): 126dB
Dynamic range @1kHz (A-wt): 126dB
Frequency Response:
20Hz-20kHz(±0.2dB)
20Hz-40kHz(±0.4dB)
Output Level:
2.1Vrms @0dBFS (4V Mode)
2.5Vrms @0dBFS (5V Mode)
Noise(A-wt): <1.3uVrms
Channel Crosstalk: -133dB @1kHz
Channel Balance: 0.3dB
Output Impedance: 50Ω
XLR
THD+N @1kHz (A-wt): <0.00006%
THD @20-20kHz 90kBw (No-owt): <0.0002%
SNR@1kHz(A-wt): 132dB
Dynamic range @1kHz (A-wt): 132dB
Frequency Response:
20Hz-20kHz(士0.2dB)
20Hz-40kHz(±0.4dB)
Output Level:
2.1Vrms @0dBFS (4V Mode)
5.0Vrms @0dBFS (5V Mode)
Noise(A-wt): <1.3uVrms
Channel Crosstalk: -149dB @1kHz
Channel Balance: 0.3dB
Output Impedance: 100Ω
Inside the Box
  • 1 x TOPPING E70
  • User Manual
