Amplifier for electrostatic headphones XLR TRS RCA input

    Powerful 700Vrms and 2000Vp-p output swing and 146dB SNR
    12V Trigger interface for easy on/off switching
    Pass-through function for seamless audio system switching
    Exceptional noise control
Regular price $399.00 USD
Sale price $399.00 USD Regular price

Unleash The Potential Of Your Electrostatic Headphones

The EHA5 is outstanding in its noise control. With an impressive 146dB SNR and noise levels below 35uVrms at low gain and 80uVrms at high gain, the EHA5, allow you to focus on every intricate detail of your music. Moreover, it boasts a remarkable 700Vrms and 2000Vp-p output swing, ensuring your electrostatic headphones perform at their peak.

Impressive Power Output With 12v Trigger Interface

The EHA5 delivers a remarkable 700Vrms and 2000Vp-p output swing, which packs a lot of power into its body. Featuring a 12V Trigger input interface, the EHA5 can easily connect with other devices for seamless on/off switching. Say goodbye to the hassle of manually powering devices on and off one by one.

Pass-through Function

The EHA5 includes a pass-through function, allowing the input signal to directly reach the corresponding balanced and single-ended outputs when the front panel is switched off. This feature is perfect for users who want to easily switch between electrostatic headphones and other audio systems when their DAC has a preamp function.

Inside the Box

  • 1 x TOPPING EHA5
  • User Manual

1 Year Warranty

The TOPPING EHA5 Comes with a 1 year warranty on the AMP & DAC only. Warranty doesn't apply to the included accessories.

Technical Details

THD+N @1kHz (A-wt)

SE: <0.0009%
BAL: <0.0009%

THD+N @20kBW(No-wt)

SE: <0.07%
BAL: <0.05%


SE: 140dB
BAL: 146dB

Dynamic range

SE: 140dB
BAL: 146dB

Frequency response

20Hz-40kHz (±2.5dB)

Noise (A-wt)

SE: <35uVrms low gain, <80uVrms high gain
BAL: <35uVrms low gain, <80uVrms high gain

Channel crosstalk


Input sensitivity

SE: 10Vrms low gain, 2Vrms high gain
BAL: 20Vrms low gain, 3.9Vrms high gain


SE: 36.8dB low gain, 50.8dB high gain
BAL: 30.9dB low gain, 44.9dB high gain

Channel balance


Output level


Bias voltage


Shipped weight



9.17" x 6.8" x 3.6" (23.3 x 17.3 x 9.3cm)
