YinLvMei B2

$289.00 USD

AK4497 DAC Portable Bluetooth DAC Amp

  • CSR8675 Bluetooth 5.0 Support LDAC,APTX-LL,APTX-HD,APTX,AAC,SBC
  • AKM AK4497 DAC Chip
  • USB DAC, Coaxial AK4118 Input and output, support 24Bit/192Khz
  • LPF - OPA1612 x2, Fully Balanced architecture, support Balanced LO Out and 4.4mm Out
  • High-precision CNC Shell and Double-Sided Tempered Glass Design
PRODUCT FEATURES
SHOP WITH CONFIDENCE
Free Shipping

Authenthic Products

Linsoul Audio is the authorized distributor. All products are authentic and genuine.

Free Shipping

Worldwide Free Shipping

We are located in china but send our products worldwide for free.

Warranty

1 Year Warranty

We provide 1 year warranty for the all products except the cables*.

Support

Online Support

We respond to all support inqueries in less than 24 hours.

PRODUCT SPECIFICATIONS
Model Number
B2
Decoding Chip
AK4497
LFP Operating Amplifier
OPA1612 x2
Bluetooth Chip
Qualcomm CSR8675
Bluetooth Version
5.0
Bluetooth Protocol
LDAC, APTX-LL,APTX-HD,APTX,AAC, SBC
Coaxial Processing Chip
AK4118 24Bit/192Khz
Support USB DAC
Yes
Input Interface
USB DAC Input, 3.5mm Coaxial Input
Output Interface
3.5mm Coaxial, 3.5mm Single-End LO, 3.5mm Balanced LO, 3.5mm Out, 4.4mm Balanced Out
Output Level Value
1.8VRMS (Single End), 3.6VRMS (Balanced)
SNR
113dB(Single End), 119dB (Balanced) @1kHz 32Ohm
Distortion
0.0008%(Single End), 0.0007% (Balanced) @1kHz 32Ohm
Output Impedance
2.2 ohm (Single End), 1.1 ohm(Balanced) @1kHz 32Ohm
Output Power
220mW (Single End), 440nW(Balanced) @16Ohm
25mW (Single End), 50mW(Balanced) @150Ohm
Size
88mm x 75mm x20mm
Weight
180g
