High-Performance Chip Integration for Detailed Audio Reproduction

Celest CD-3 combines the KT02H20 digital audio codec chip with the OPA97220 headphone amplifier, integrating decoding and amplification systems for enhanced audio performance. Supporting up to 384kHz/32bit PCM decoding, it accurately reproduces musical details with clear and high-fidelity sound.

Flexible Output Options for Different Listening Setups

Featuring both 4.4mm balanced and 3.5mm single-ended outputs, CD-3 supports different headphone connections. The 4.4mm balanced output adopts a 5-pole design with independent positive and negative signal transmission to reduce interference and improve channel separation.

Tuned Output Performance with Reliable Driving Power

Professionally tuned for 16-32Ω headphones, CD-3 delivers 30mW@32Ω through the 3.5mm single-ended output and 120mW@32Ω through the 4.4mm balanced output. The dedicated amplifier chip provides stable driving power for IEMs and entry-level over-ear headphones.

UAC2.0 Protocol for Plug-and-Play Compatibility

Powered by the UAC2.0 universal audio protocol, CD-3 enables plug-and-play operation without additional drivers. It supports Windows, macOS, Android, iOS, and HarmonyOS for seamless connection with smartphones, laptops, and tablets.

Compact Design for Portable HiFi Listening

With a compact size of 48×20×11mm and a weight of only 20.4g, CD-3 is designed for easy portability. Its low-power circuit draws power directly through the Type-C port, ensuring stable power delivery and data transmission.

Technical Details

Product Name
Celest CD-3 Portable DAC/Amp
DAC Chip
KT02H20 + OPA97220
Output Power
30mW@32Ω (3.5mm SE), 120mW@32Ω (4.4mm Bal)
PCM Format Support
Up to 384kHz/32bit
Headphone Jack
3.5mm Single-Ended + 4.4mm Balanced
Output Ports
USB Type-C
Frequency Response
20Hz~20kHz (+3dB)
Signal-to-Noise Ratio
>100dB
Dynamic Range
>100dB @1kHz
Total Harmonic Distortion
≤0.018% @1kHz
Dimensions
48x20x11mm
Weight
20.4g
OS Compatibility
Windows / macOS / Android / iOS / HarmonyOS
Inside the Box
  • Celest CD-3 Portable DAC/Amp x 1
  • User Manual x 1

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The Celest CD-3 Comes with a 1 year warranty on the AMP & DAC only. Warranty doesn't apply to the included accessories.

Processing Time

This product is currently in its pre‑order period. Pre‑orders apply to items not yet in stock, and shipping will begin once they arrive. Processing times are estimates only.

Pre-order Period:

  • 3-4 days

Note:

  • No cancellation of orders once ordered.
  • All orders to be shipped out sequentially.
